YX3系列高效三相异步电动机
产品说明:

YX3系列电机系列全封闭、外扇冷式、鼠笼型机构。该系列电机是国内第一个完整的全系列采用冷轧硅钢片为导磁材料的低压笼型三相异步电动机基本系列。具体设计新颖、造型美观、噪音低、转矩高、启动性能好、结构紧凑、使用维护方便等特点。其效率完全符合GB18613-2012《中小型三相异步电动机能效限定值及节能评价值》的规定,采用F级绝缘,且全系列温升按B级考核,从而大大提高了安全可靠性。电机的安装尺寸符合IEC标准规定,电机的外壳防护等级为IP55。

YX3系列电动机可广泛应用于机床、风机、水泵、压缩机和交通运输、农业食品加工等各类机械传动设备。

YX3 series are totally enclosed fan-cooled squirrel cage structure motor.this series motor is the first product which adopts cold-rolled silicon sheet in domestic market,with the feature of novel design、beautiful modeling、lownosie、high torque、compact structure、excellent starting performance、easy maintenance and so on.The efficiency conform to regulation of 《efficiency limits and energy-saving evaluation》.the motor’s safety and reliability are greatly enhanced because of F class insulation and ip55 protection class on outer cage. Mounting dimensions are conformed to IEC standard.
YX3 series motors can be widely used for driving equipments of various machineries,such as machine tools、blower、pumps、compressors, transport、agricultural and food processing.
产品使用条件 WORKING CONDITION
额定功能范围:0.12~315kw
基本极数:2、4、6、8、10级
功率:50HZ
电压:380V
冷却方式:IC411(外循环表面冷却)
接法:3KW以下为Y接,4KW以上为Δ接法
定额:连续S1
环境温度随季节而变化,但最高不超过40℃,最低不
低于-15℃,海拔不超过1000米
The range of rates power :0.12kw-315KW
Basic pole:2、4、6、8、10poles
Frequency:50HZ
Voltage:380V
Cooling method:IC411
Connection method:“Y”connection for 4KW connection method,
“△”connection for 4KW and above Working duty:continuous duty S1
The environment temperature is ranged form-15℃ to 40℃,the altitude is no more than 1000m.
